型号

Part No.

管内径

I.D(mm)

接头管螺纹

（G")

长度

Length(mm)

弯曲半径

Bending Radius(mm)

EXR700xG1/2"15.01/2"70080EXR1000xG1/2"15.01/2"100080EXR700xG3/4"20.03/4"700110EXR1000xG3/4"20.03/4"1000110EXR700xG1"25.01"700145EXR1000xG1"25.01"1000145EXR700xG1‐1/4"32.01‐1/4"700160EXR1000xG1‐1/4"32.01‐1/4"1000180EXR700xG1‐1/2"40.01‐1/2"700210EXR1000xG1‐1/2"40.01‐1/2"1000210EXR700xG2"50.02"700250EXR1000xG2"50.02"1000250EXR700xG2‐1/2"70.02‐1/2"700350EXR1000xG2‐1/2"70.02‐1/2"1000350EXR700xG3"80.03"700400EXR1000xG3"80.03"1000400EXR700xG4"100.04"700500EXR1000xG4"100.04"1000500

适用范围：

1区 2区危险场所。

ⅡA、ⅡB、ⅡC  类爆炸性气体环境。

产品特点：

具有耐燃、耐腐蚀、耐水、耐老化、挠性良好、结构牢固、工作可靠等优点。 橡胶防爆挠性连接软管长度，可根据用户需要特殊加工。配套碳钢内丝、外丝接头螺纹标准有:  英制G螺纹、美标NPT螺纹、 公制ISO等。

标注螺纹规格时应注明内、外丝螺纹。 产品符合GB3836‐2000,IEC60079标准要求。
