进店逛逛1、产品特点Features
搅拌单元不接触物料.No direct touch between stirring unit and materials.
搅拌动作更加轻柔，不破坏物料的原有外形特征.Light stirring, no damage to the materials.
提高料斗中物料的流动性、优化螺杆填充度、使流速更加稳定.Improve material flow and optimize dynamic loadings of thescrews.
目前国际上解决粉料失重喂料的好方案Ideal and leading solution and design of powder lose-in-weightfeeders
2、技术参数Parameter
参 数Parameters 型号 型号Model | FP-48 | FP-63 | FP-76 | FP-89 |
流量范围Capacity range | 20-100kg/h | 50-300kg/h | 100-600kg/h | 200-1200kg/h |
料斗容积Volume | 40L | 100L | 200L | 250L |
传感器量程Range | 50kg | 100kg | 250kg | 300kg |
重量Net Weight | 86kg | 140kg | 170kg | 200kg |
外形(长x宽x高)Size | 550x340x680 | 680x430x900 | 790x480x1050 | 820x490x1150 |
电源Power | AC380V 3相 喂料0.25kw +搅拌0.15kw | AC380V 3相 喂料0.37kw +搅拌0.2kw | AC380V 3相 喂料0.55kw +搅拌0.4kw | |
输出方式 | 弹簧或实心单螺杆Granule Screw | |||
动态相对误差Dynamic accuracy | ±0.5% | |||
小重量分辨率Min.sensitivity | 1g | 2g | ||
出料简规格Discharge tube | Φ48x3 | Φ63x3 | Φ76x3 | Φ89x3 |
※1、流量范围值以堆积密度=0.6g/ml物料作测试
Capacity range value is calculated basedon materials with stacking density 0.6g/m
※2、动态相对误差值以非补料状态大于30秒的采样周期作测试
Dynamic accuracy vale is tested based onworking condition status longer than at least 30 seconds.
